FRAME+ 100/120 RI - Rooflight window

Product Objects

  • Cross section

    FRAME+100 RI – Variant stepped edge glazing

With its new FRAME+ 100/120 RI rooflight window, RAICO is once again opening up a range of new possibilities in the field of functional and aesthetic roof design – thanks to their special depth of section, passive house certification and lean, elegant appearance which perfectly matches the proven THERM+ roof and curtain wall systems.

Advantages

  • Innovative insulating bar material THERMORIT with very low thermal conductivity and suitable for composite coating and anodising
  • Stepped glass variant optionally available either in unilateral design or with circumferential full glass finish with identical outer and sash frame
  • Various glass step variants available for a circumferential glass step (F-strip, suction disc)
  • Two different glazing variants due to the option for the screw connection of the cover profile (visible or concealed)
  • High degree of tightness by three peripheral seal levels with medial gasket frame
  • First passive house certified „opening element in the glass roof“

Technical specifications

Uw-value1 passive house = 1.0 W/(m2K)
Uf-value2 ≥ 1.40 W/(m2K)
System depth 80/100/120 mm
Applications Opening element in the glass roof
Application limits3
Max. weight turn-tilt
surface-mounted fitting		 225 kg
Max. weight turn
surface-mounted fitting		 225 kg
Max. weight
consealed fitting		 –
Max. sash dimensions4 3,500 x 1,500 mm /
2,100 x 2,500 mm
Infill thickness sash 10 to 80 mm
Infill thickness fixed glazing 11 to 68 mm

1 Determined with glass Ug = 0.7 W/(m2K)
2 Thermal insulation based on DIN ISO 10077-2
3 Applications outside these limits, would be subject to an assessment by our Technical Department
4 For authorized sash sizes, see fitting diagram in the relevant planning documents

Tests / Approvals

Tests
according to product standard for windows and exterior doors EN 14351.1
Air permea­bility1 Class 4
Resistance to wind load1 Class C3/C4*
Resistance against impact1 –
Water tightness1 up to E 1500
Operating forces1 –
Airborne sound insulation2 Rw (C; Ctr) up to 43 dB
Mechanical strength1 –
Burglar resistance Class RC2
Continuous-operational
testing EN 12400		 Class 3

1 Tested to RAL GZ 695
2 The values are referred to the standard size of 1.23 x 1.48 m
* Values are maxium tested/max. classification
The classification must be realized according to the requirements of the specifications.

Variants

Passivhaus

The climatic change and the energy transition represent comprehensive challenges, in particular to energetic building and renovation. Our passive house-certified window system fulfils these requirements, thus achieving maximum energy-saving potential.

more

Einbruchhemmung

By using additional components, the RAICO window system can be equipped with burglary-resistant properties in resistance class RC2.

more
