- Uf- value2
- ≥ 1,4 W/(m2K)
- System depth
- 100 / 120 mm
- Applications
- Opening panel in the glass roof
- Max. weight turn-tilt surface-mounted fitting
- 225 kg
Cube Berlin
| Location / City | Berlin, Deutschland |
|---|---|
| Year of Construction / Completion | 2019 |
| Construction Type | New Construction |
| Architect / Architectural Firm | 3XN Kopenhagen |
| Contractor | GIG Fassaden GmbH |
| Client | CA Immo |
Reference
- System depth
- 75 mm
- Applications
- Wall panel
Facade insert
Leaf-enclosing panel sections - Minimum width of the active leaf
- 310 mm
- Minimum width of inactive leaf
- 310 mm
FRAME+ 75 DI – Aluminium door
- Uf- value2
- ≥ 1,0 W/(m2K)
- System depth
- 75 mm
- Applications
- Wandfenster
Fassaden-Einsatzelement - Max. weight turn-tilt surface-mounted fitting
- 130 / 160 / 200 kg*
FRAME+ 75 WI – Insertion window
- System width
- 50 / 56 / 76 / 96 mm
- For steel profiles from
- 50 mm width
- Steel profiles in T shape
- 60 mm width, 60 / 90 / 120 mm depth
- Infill thickness
- 4 – 64 mm
THERM+ S-I – Steel façade
- System width
- 50 / 56 / 76 / 96 mm
- For steel profiles from
- 50 mm width
- Steel profiles in T shape
- 60 mm width, 60 / 90 / 120 mm depth
- Infill thickness
- 4 – 64 mm
